GR2 Titanium Clad Steel Plate

1. product Introduction

GR2 titanium clad steel plate began in 1962. At that time, the production method was called the "explosive clad method", which was a method of bonding by virtue of the explosive energy of explosives. The hot rolling method and thick plate rolling method were developed in 1986. In 1990, the production method of the continuously hot-rolled coil was developed, mainly referring to the production of thin plates. Titanium has high strength, and the maximum tensile strength of pure titanium can reach 180kg / mm2. Titanium is widely used as various chemical reaction vessels and heat exchangers because of its excellent corrosion resistance, but the disadvantage is that the cost is high. The composite of Gr2 titanium and ordinary steel is called GR2 titanium clad steel plate. It has both the corrosion resistance of titanium and the strength of ordinary steel plate as a structure. The important thing is that the cost has also been greatly reduced.



ASTM (B265)	Chemical Composion (%)							Residuals
	C	H	0	N	Fe	Pd	Ti
Grade 2	≤0.08	≤0.015	≤0.25	≤0.03	≤0.30		balance	each≤0.1 total≤0.4



Grade	Class	chemical elements					method of deoxidation
		C %	Mn %	Si %	S %	P %
Q195	—	0.06-0.12	0.25-0.50	0.30	0.050	0.045	F,b,Z
Q215	A/B	0.09-0.15	0.25-0.55	0.30	0.050/ 0.045	0.045	F,b,Z
Q235	A	0.14-0.22	0.30-0.65	0.30	0.050	0.045	F,b,Z
	B	0.12-0.20	0.30-0.70	0.30	0.045	0.045	F,b,Z
	C	<0.18	0.35-0.80	0.30	0.040	0.040	Z
	D	<0.17	0.35-0.80	0.30	0.035	0.035	TZ
Q255	A/B	0.18-0.28	0.40-0.70	0.30	0.050/ 0.045	0.045	z
Q275	—	0.28-0.38	0.50-0.80	0.35	0.050	0.045	Z



2. Production process

Explosion bonding

3. Qualification Certificate

EHS and ISO Certificate

4. Why choose us

After more than ten years of rapid development, our company now has a group of subsidiaries such as Baoji Taicheng Metal Co., Ltd., Baoji New Taicheng Metal Composite Co., Ltd., Baoji Taicheng Pressure Vessel Equipment Manufacturing Co., Ltd., Fujian Sanqin Titanium Industry Co., Ltd., Sichuan Taicheng Titanium Industry Co., Ltd. Adhering to the concept of "innovation, development, cooperation and win-win". As a GR2 titanium clad steel plate manufacturer, Taicheng Group continues to promote scientific and technological progress and industrial upgrading development, provide customers with high-quality products and first-class services, actively expand and strengthen the new industry of metal composites, make unremitting efforts to build a first-class national innovative enterprise of metal composites and create a new life of green and environmental protection.
