1. Product description
Type:
The cladding material can be coated on one or both sides of the substrate to form a single-sided or double-sided clad plate.
The shapes of ASTM stainless steel clad steel plate sheet are rectangular, square, and circular. Other shapes can be agreed by the supplier and the buyer.
2. Dimensions
1) Application: vessel, exchanger
2) Size range: TK:Base plate:7-500mm
cladding plate:1-14mm
Diameter:φ200-φ6000mm
3) Bonding method: explosion
3. Product Features
Size | Technique | Material | Punching or not | Payment |
Diameter: ≤10000mm Thickness: 2-300mm | Explosive bonding or Hot rolling | Steel plate: ASTM A36 ASME SA516 Gr60,Gr60N, Gr60HIC, Gr65, Gr65HIC, Gr65N,Gr70, Gr70N,Gr70HIC ASME SA537 Gr1 Gr2 Gr3 ASME SA105 ASME SA350 LF1 LF2 LF3 ASME SA387 Gr11, Gr12, Gr21, Gr22 ASME SA187 F1,11,12,21,22 ASME SA266 Gr1,Gr2,Gr3, Gr4 etc. Cladding plate: ASME SA240 304/304L,310/310S 316/316L,316H,316Ti,317/317L ASME SA240 321,321H,347,347H ASME SA240 430, 405, 410, 410S ASME SA240 UNS S32205, S32304,S32750,S32760,S31803, S32507 AL6 XN(N08367) 904L etc. | Customizable according to your drawings | T/T, L/C, DP or Negotiable |
4. Application
Petro-chemical, Chlor-alkali, Metallurgical, Food, Medicine, Auto Industry, Electrolytic Aluminum, Power Industry, Electrolysis Industry, Hydrometallurgy, Vacuum Salt Industry, Light Industry, Fertilizer, etc.
5. Packaging, marking, and quality certificate
Each composite plate must be inscribed on the surface of the cladding material at the end of the steel plate with the product mark, batch number, manufacturer's name (or factory logo), manufacturing date, etc.
When delivering the ASTM stainless steel clad steel plate sheet, the product quality certificate (original) of the composite plate shall be provided, and copies of the quality certificates of the covering material and the base material shall be provided at the same time.
The surface of the composite plate shall be effectively protected to prevent scratches.
Other requirements shall be in accordance with ASTM A264.
6. Why choose us
After more than ten years of rapid development, our company now has a group of subsidiaries such as Baoji Taicheng Metal Co., Ltd., Baoji New Taicheng Metal Composite Co., Ltd., Baoji Taicheng Pressure Vessel Equipment Manufacturing Co., Ltd., Fujian Sanqin Titanium Industry Co., Ltd., Sichuan Taicheng Titanium Industry Co., Ltd. Adhering to the concept of "innovation, development, cooperation and win-win". As a manufacturer of ASTM stainless steel clad steel plate sheet, Taicheng Group continues to support advancement in science and technology as well as industrial development, offer customers high-quality goods and first-rate services, actively develop the new metal composites industry, put forth the unceasing effort to establish a world-class national metal composite innovative enterprise, and usher in a new era of environmental protection.
7. FAQ
After-sale
(1) the company has a special after-sales department and after-sales service personnel
(2)service timeliness rate ≥ 95: customer satisfaction rate ≥ 95%: customer complaint rate (really belonging to service responsibility) < 2%.
(3) The after-sales service department is responsible for the collection of customer feedback information, the acceptance of complaints, the return, replacement, and maintenance of products, and timely informing the customers of the handling opinions and results.
