1. Product Description

In the reaction process of the TA section, there is acetic acid corrosion, and many equipments are lined with titanium materials. In the PTA section, because catalyst palladium and products are sensitive to metal ions such as Cu²﹢、Cr²﹢、N﹢、Fe³﹢, these metal ions have toxic effects on palladium and reduce product quality. Therefore, titanium is also selected as the material. Titanium cladding plates are selected according to the requirements of the process and cost Manufacture of PA-PTA equipment with titanium-clad stainless steel clad steel three-layer clad plate.

2. Product Specifications

Allowable deviation of overall dimension:

Composite welding is allowed for composite plates with a width greater than 1100mm or lengths greater than 3000mm.

The thickness of cladding metal is generally 1.5mm ~ 10mm, and the cladding metal of composite plate can be composed of multi-layer composite. The allowable deviation of the composite thickness of the explosive composite plate shall not be greater than ± 10% of the nominal thickness of the composite; The allowable deviation of the thickness of the explosive rolled composite plate and rolled composite plate shall not be greater than - 10% ~ + 20% of the nominal thickness of the composite.

3. Product Features

(1) Without the magnetization effect, the resistance coefficient and thermal conductivity of industrial pure titanium are similar to those of stainless steel.

(2) Industrial pure titanium is a self-protective metal, and surface scratches can heal automatically.

(3) Industrial pure titanium is used for compounding in the annealed state, with good processing ability. (similar to stainless steel)

titanium cladding sheet

4. Applications

1）Equipment field

The application in the field of equipment mainly refers to the chemical equipment of similar para phthalic acid manufacturing equipment and the power equipment of condenser tube sheets for power plants. In particular, the shipment volume in the power field has reached more than 1000. This field is the pillar industry of titanium cladding plates. Recent topics: Titanium cladding sheet is also used in bleaching treatment tanks in paper mills and sodium hypochlorite treatment tanks in sewage treatment plants.

2）Maintenance of marine structures

Japan is surrounded by the sea, and the base of economic activities is located in the offshore area. With the needs of economic development, the space of circulation, transportation, urban functions, and other facilities is using the sea area and is developing from the shallow sea area of the inland sea and inner bay in the past to the open sea and deep sea area now. To this end, Japan has set up a super large floating technology research group to conduct theoretical research and field tests on super large floating marine structures with a scale of several kilometers and durability of 100 years. Titanium material has the advantages of excellent corrosion performance, few dissolved ions in seawater environment, non-toxic, and no need to worry about polluting the environment. Therefore, it has become the preferred material for marine structures.

5. Package

The titanium cladding plate is bare. The two sides of the cladding metal are opposite, the middle is lined with moisture-proof paper, and the outside is bound with metal wire. If there are special requirements for packaging, the supplier and the buyer shall negotiate.

Products shall be protected from collision, moisture, and erosion of active chemicals during transportation and storage.

6. Why choose us

After more than ten years of rapid development, our company now has a group of subsidiaries such as Baoji Taicheng Metal Co., Ltd., Baoji New Taicheng Metal Composite Co., Ltd., Baoji Taicheng Pressure Vessel Equipment Manufacturing Co., Ltd., Fujian Sanqin Titanium Industry Co., Ltd., Sichuan Taicheng Titanium Industry Co., Ltd. Adhering to the concept of "innovation, development, cooperation and win-win". As a manufacturer of titanium cladding plate, Taicheng Group continues to promote scientific and technological progress and industrial upgrading development, provide customers with high-quality products and first-class services, actively expand and strengthen the new industry of metal composites, make unremitting efforts to build a first-class national innovative enterprise of metal composites and create a new life of green and environmental protection.

titanium cladding

7. FAQ

Principle of rolling clad method?

There are two kinds of rolling compound methods, cold rolling, and hot rolling. The basic principle is: under the strong pressing action of a rolling mill, or the combination of preheating action, plastic deformation occurs on the cross-section of two metal materials to be compound, resulting in plastic deformation or fracture of the surface to be compound, and then clean, activate, and continue to form a planar metallurgical bonding form under the action of strong stress. It is different from single metal rolling in that a strong pass reduction must be applied, especially the initial pass. Only under this condition can the physical contact between the two metal materials to be compounded be made as full as possible.
