1. Product Introduction

Grade 7 titanium sheet belongs to high temperature resistant titanium plate. The Grade 7 titanium alloy sheet still has high specific strength in the range of 150-500 ℃, while the specific strength of aluminum alloy decreases obviously at 150 ℃.

2. Product parameters

Tensile requirements and chemical requirement of titanium sheet

Under 0.070 in.(1.8 mm) in Thickness

Grade	Tensile Strength, min		Yield Strength, 0.2 % Offset				Elongation in 2 in. or 50 mm, min, %	Bend Test (Radius of Mandrel)
	ksi	MPa	min		max			Under 0.070 in.(1.8 mm) in Thickness	0.070 to 0.187 in. (1.8-4.75 mm) in Thickness
	ksi	MPa	ksi	MPa	ksi	MPa		Under 0.070 in.(1.8 mm) in Thickness	0.070 to 0.187 in. (1.8-4.75 mm) in Thickness
1	35	240	20	138	45	310	24	1.5T	2T
2	50	345	40	275	65	450	20	2T	2.5T
3	65	450	55	380	80	550	18	2T	2.5T
4	80	550	70	483	95	655	15	2.5T	3T
5	130	895	120	828	...	...	10	4.5T	5T
6	120	828	115	793	...	...	10	4T	4.5T
7	50	345	40	275	65	450	20	2T	2.5T
9	90	620	70	483	...	...	15	2.5T	3T
11	35	240	20	138	45	310	24	1.5T	2T
12	70	483	50	345	...	...	18	2T	2.5T
